PVC pipe fitting mould - collapsible core structure type
Ø Collapsible core design with cooling system from dia. 32mm to dia. 400mm
Ø Use twice tooling: Rough tooling and then precision tooling after treatment
Ø Design mold size as small as possible without compressing mould quality
Ø Limit switch for slider stroke control and prolong mould life
Ø Fulfill multi direction collapsible core system fitting shape
Ø Reasonable gate location and runner system
Ø Interchangeable mold inserts
PVC pipe fitting mould - unscrewing core structure type
A) Motor drive for unscrew core ejection, full automatic dropping part
B) Unscrewing stroke is 1/3 short than traditional mould design which short mould cycle time by 10S.
C) Optimal cooling system for core, cavity and screw core
D) Experience screw dimension controlling system
PVC pipe fitting mould - curve structure type
PVC pipe fitting mold - normal mechanical or hydraulic side system
